Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg

    Buy cheap Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg from wholesalers

    Buy cheap Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg from wholesalers
    • Buy cheap Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg from wholesalers
    • Buy cheap Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg from wholesalers

    Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg

    Ask Lasest Price
    Brand Name : DORHAUS, Dorrenhaus
    Model Number : D30
    Certification : UL 228, ISO9001:2015
    Price : USD19.50.00- USD21.00 /pc
    Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 20,000 pcs / month
    Delivery Time : around 35 days
    • Product Details
    • Company Profile

    Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg


    Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg

    • No oil leakage, no abnormal noise, smooth running
    • Large closing force, the largest optional for 80kg door
    • Two steps speed adjustment of closing and latching


    Dorrenhaus automatic hydraulic door closer D30 concealed type, mainly designed
    for hotel room door. If necessary hold open unit can be installed or removed easily.
    Anyhow, Most local building codes do not allow the installation of any type of door
    hardware that holds "Fire Doors" in the open position.

    * Door Closer Concealed Rack & Pinion type with EN size 3
    * Fully hydraulically adjustable closing and latching speed
    * Suitable for max door weight 65kg and door width 950mm
    * Precise cast aluminum body with alluminum hidden sliding arm
    * Minimun door thickness for installation
    - 45mm for wooden door and 40mm for sash door
    * Certification of UL 228, 200,000 + life cycles
    * Universal application, non-handed installation
    * Certification of UL 10C, fire rated up to 3 hours

    Reliable cooperative vendors of universal well-known door control enterprises


    Closer Finishes- Silver, Bronze, Gold, Brown, Black, White

    * GENTLE, HANDS-FREE CLOSING: let the door finish work, enjoy self-acting closing and
    locking, keep quiet and safety.
    * SKILLED WORKMANSHIP: even running, oil tight, noiseless
    * SPRING THRUST, EASY CLOSING: commercial-level sliding arm will not impact opening,
    while closing doors slowly enough to allow graceful entrance and exit

    Closing
    Strength

    Min. Door
    Thickness

    Max. Door
    Open Angle

    Fireproof
    Standard


    Tested Life Cycles


    size 3

    45mm150ºUL 10C - 3H200,000


    Type No.

    Width
    Suitable

    Max. Door
    Weight

    Body Size
    (LxWxH)

    Mounting Dim.


    D30

    950mm40-65kg312*32*76mm

    298*20mm


    Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kgConcealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg
    Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg

    Concealed Automatic Door Closer With Hidden Sliding Arm Max Door Weight 65kg
