Surface Mounted Door Closer D8016 Heavy Duty Hydraulic Automatic Size Adjustable

Surface Mounted Door Closer Heavy Duty Hydraulic Automatic Size Adjustable

• Comform to ANSI/BHMA A156.4 Grade 1 Standard, UL/c UL Listed
• Max. Tested Life cycles of 5,000,000 plus, 3 hours Fire Rating Test
• Advanced Technology: smooth running, oil tight, no abnormal noise

SPECIFICATION:

Finish: Aluminum (ALU), Dark Bronze (DURO), Brown, Gold, Black, White
Powder Coated Finished Body to enhance corrosion resistance
Feature: Grade 1, Commercial, Surface Mounted, Heavy Duty.
Material: Cast Aluminum body. Steel arm. Heat Treated Piston and Pinions.
Adjustable: 3 valves regulating backcheck, closing and latching speed.
Tri-Pack screw package (Regular, Top Jamb, and Parallel Arm Mount)
Spring Size Adjustable through 1 to 6 (Spring Pre-Set as #3).

Use for doors weight up to 331lbs and 59.1 inches width


TESTED AND CERTIFIED:

ANSI/BHMA 156.4:
UL/cUL Listed:
Grade 1 tested for 2,000,000+ cycles
ADA Compliant

WARRANTY:

3 YEAR WARRANTY

► 8 Years Cooperative Supplier of World's First-rate Security Brands

Finishes: Brass, Brown, Aluminum, Bronze, White, Black

* GENTLE, NO MANUAL CLOSING: the door will closer by itself, enjoy self-acting

closing and locking, keep quiet and safety.

* SKILLED CRAFT: even operation, oil tight, noiseless

* SPRING THRUST, EASY CLOSING: the commercial-grade arm won’t interfere with

opening, while closing doors slowly enough to allow graceful entrance and exit

* TRUSTABLE CERTIFICATION: ANSI 156.4 - Grade 1 is the highest standard for

door closers. This model is actually super passed 2 million+ cycles testing.

* ADJUSTABLE TO YOUR NEEDS: let customer act at their own pace. which level

should be adapted for closing power: from level 1 to level 6.

* MEET YOUR REQUIREMENTS: surface mounted model and full sets of screw

package, allow you to install at different occasion, and is completely controlled.

           ------------ Our Advantages ------------

                     1.   Only produce door closer, annual output 1.5-2.0mils pcs.

                     2.   UL & CE certification, max. Life cycle test of 5 mil. Cycles.

                     3.   Pass European & China ISO9001:2015 QMS Certification.

                     4.   Mainly for export market since foundation in October, 2011.

                     5.   Long term cooperative supplier of world’s top security brands.

A High-end Germany Gating Hardware Brand

Originally founded in 1872, Dorrenhaus is a high-end Germany gating hardware brand. At the beginning of 1980's,

Dorrenhaus entered into Chinese market, and supplied numerous households in China with high quality hardware products.

On October 10, 2011, Dorrenhaus's door closer manufacturing base in China - Zhejiang Dorrenhaus Hardware Industry Co.

Ltd was formally founded. All members of management team have more than 15 years of experience in door closer industry.

Marketing Under Dorrenhaus and DORHAUS Brand

In 2017, our new trademark - DORHAUS was registered. We have $3 million registered capital. Our main products include

hydraulic door closers, automatic door closers, concealed door closers, commercial door closers, fire door closers, auto door

closers, sliding door closers, heavy duty door closers, overhead door closers, UL-listed door closers and door closer parts.

We have 205 total number of employees, which includes seven R&D staff and 13 quality control staff in our

15,000-square-meter factory.

Exporting Products Worldwide

Now, we have six complete production lines with annual output of 1.5 to 2.0 million sets. We export our products to more than

20 countries in North America, Europe, Russia, the Middle East and Southeast Asia. We passed the certification for EN ISO

9001:2008 quality management system in 2014, and ISO9001:2015 in 2017 respectively.

Our products passed many international and domestic certification and standard, such as:

American National Standard: ANSI 156.4 Grade 1, life cycle test of 2mil cycles

American UL228 and UL 10C for 3 hours fire testing

European Standard CE: EN1154, life cycle test of 500,000 cycles

European Standard CE: EN1634 fire testing

China National Standard: QB/T 2698-2005 Grade 1, life cycle test of 1 mil. cycles

China Compulsory Product Certification for fire rated door closer

Cooperate with Us Today

For more detailed information regarding our business, contact us today.
